Highlights

Category

Touring

Class

Can be configured to a Class 1, 2, or 3 E-Bike.

Frame Type

Low-step

Seating

Relaxed

Perfect For

Paved / Light Trails / Recreation

THE BATTERY.

The Pilot Hub’s fully integrated 15Ah battery lasts up to 50 miles per charge. It surpasses UL certification standards and is color-matched for a classic appearance.

15Ah

50 miles (80 Kilometers) Max Range

7.5 Hours Charge Time

RESPONSIVE PAS CONTROL

Smooth torque sensor

Cadence sensors only respond to how quickly you pedal — but the Pilot Hub’s torque sensor focuses on effort. Pedal casually for light assistance or go all out to get more power!

Component Overview

Electronic Details

Motor Brand

Bafang

Motor Type

Hub-Drive

Motor Nominal Output

500W

Motor Peak Output

750 Watts

Battery Voltage

48 Volts

Battery Ah

15Ah

Battery Wh

720Wh

Battery Chemistry

Li-NMC, UL2271 & UL2849 Certified

Battery Charge Time (from empty)

7.5 Hours

Minimum Range

25 Miles (40 Kilometers)

Maximum Range

50 miles (80 Kilometers)

Display Type

Magnum Branded VeloFox, 8 x 7 cm. Display Screen, Backlit Monochrome LCD

Display Readouts

Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip Time

Drive Mode

Torque Sensor Pedal Assist, Thumb Throttle, Walk Mode

Top Speed

Up to 28 mph with Pedal Assist, 20 mph with Throttle

Lights

Integrated front and rear lights

Mechanical Details

Frame material

Aluminum Alloy

Frame Type

Low-step

Fork Details

Suspension 100mm travel with Lock-Out

Gearing details

Shimano 8 Speed 11-32T

Shifter Details

Shimano 8-Speed

Crank

Aluminum Alloy 170mm

Pedals

Wellgo

Stem

Tool-free Adjustable

Brakes

Tektro Hydraulic

Grips

Brown Faux Leather

Saddle

Selle Royal Freeway

Tire Brand

26 x 3.0

Wheel size

26”

Fenders

Front and Rear Included

Chain

KMC 8-Speed

Measurements

Seat Tube

17.5″ (44 cm)

Reach

16.75″ (42.5 cm)

Stand Over Height

19.25″ (49 cm)

Virtual Top Tube Length

23.25″ (59 cm)

Min Saddle Height

23″ (58 cm)

Max Saddle Height

29.25″ (74 cm)

Width

27″ (69 cm)

Wheelbase

48″ (122 cm)

Length

76″ (193 cm)

Total Weight

74.5 lbs (33.75 kg)

Battery Weight

8.5 lbs (3.9 kg)

Recommended Minimum Rider Height

5’0″

Max Load Capacity

What’s Included

Kickstand

Includes Center-Mounted Single Side Adjustable Length Kickstand

Bell

Includes Bell

Charger

Includes 54.6V 2A Charger

Front Rack

N/A

Rear Rack

Includes Rear Rack

Fenders

Includes Front and Rear Fenders

Accessory Mounts

Includes Built-In Head Tube and Top Tube Accessory Mounts
